CRY711 Ear simulator/coupler
Ear simulator/coupler is a device that simulates the physical characteristics of the human ear. It includes a microphone and an acoustic network with a structure similar to the acoustic characteristics of the human external ear. It is used to make quantitative and qualitative evaluations of the performance of headphone equipment.
1、Compliance with IEC 60318-4:2010 Occluded – ear simulator for the measurement of earphones coupled to the ear using ear inserts
2、Compliance with ITU-T Rec. P.57(2011) Type 2
3、Compliance with SJ/T 10659-1995 Occluded-ear simulator for the measurement of earphones coupled to the ear-by-ear inserts
Frequency Response Curve of CRY711 Ear Simulator
1、Elaborate design, sophisticated materials and precision manufacturing ensure excellent product consistency.
2、With the built-in CRY372 pressure-field pre-polarization measurement microphone, it can give its performance into full play.
| CRY711 Ear Simulator / Coupled Cavity |
|---|
| Applicable Standards | IEC 60318-4（IEC60711）
ITU-T Rec. P.57 Type 2 |
| Resonant frequency | 13.5kHz±1kHz |
| Frequency range (±1 dB) | 100Hz～10kHz (stimulating human ear impedance) |
| Frequency range | 20Hz～16kHz (for coupled cavity) |
| Height | 23mm (excluding microphone) |
| Diameter | 23.77mm |
| Weight | 45g (excluding microphone) |
| Exampled of Options & Configuration Checklist |
|---|
| Example | Example 1 | Example 2 | Example 3 |
| Preamplifier |
CRY502 (traditional DB9 port) CRY506 (ICP, BNC port) |
CRY508 (ICP, BNC port) | CRY509 (traditional aviation plug) |
| Connection mode | Preamplifier with cable | BNC-specific cable | Aviation plug-specific cable |
| Images |  |
 |
 |
