IT8500+ Programmable DC Electronic Load

IT8500+series (150W~3000W) single-channel programmable DC electronic loads are designed for middle & high-end applications. They can be offered as multiple solutions according to the customer’s design and testing requirements. The user can perform online voltage measurements and adjustments or simulate short circuit tests using the simple keypad on the front panel. IT8500+ series DC loads are a versatile instrument for static and dynamic testing of power supplies, batteries, DC-DC converters, and battery chargers, providing users with the best testing solution.

IT8500+ Programmable DC Electronic Load

Model	Voltage	Current	Power	Resolution	Accuracy	Interface	Size
IT8511A+	150V	30A	150W	0.1mV/1mA	±(0.025%+0.025%FS)/ ±(0.05%+0.05%FS)	Built-in LAN/USB/RS232/GPIB/CAN/External analog control interface	½ 2U
IT8511B	500V	10A	150W	1mV/0.1mA	±(0.025%+0.025%FS)/ ±(0.05%+0.05%FS)	Built-in LAN/USB/RS232/GPIB/CAN/External analog control interface	½ 2U
IT8512A+	150V	30A	300W	1mV/0.1mA	±(0.025%+0.025%FS)/ ±(0.05%+0.05%FS)	Built-in LAN/USB/RS232/GPIB/CAN/External analog control interface	½ 2U
IT8512B+	500V	15A	300W	1mV/0.1mA	±(0.025%+0.025%FS)/ ±(0.05%+0.05%FS)	Built-in LAN/USB/RS232/GPIB/CAN/External analog control interface	½ 2U
IT8512C+	120V	60A	300W	1mV/0.1mA	±(0.025%+0.025%FS)/ ±(0.05%+0.05%FS)	Built-in LAN/USB/RS232/GPIB/CAN/External analog control interface	½ 2U
IT8512H+	800V	5A	300W	1mV/0.1mA	±(0.025%+0.025%FS)/ ±(0.05%+0.05%FS)	Built-in LAN/USB/RS232/GPIB/CAN/External analog control interface	½ 2U
IT8513A+	150V	60A	400W	0.1mV/1mA	±(0.025%+0.025%FS)/ ±(0.05%+0.05%FS)	Built-in LAN/USB/RS232/GPIB/CAN/External analog control interface	½ 2U
IT8513B+	500V	30A	600W	1mV/1mA	0.02%+0.025 %FS/0.1%+0.1%FS	Built-in LAN/USB/RS232/GPIB/CAN/External analog control interface	½ 2U
IT8513C+	120V	120A	600W	0.1mV/1mA	±(0.025%+0.025%FS)/ ±(0.05%+0.05%FS)	Built-in LAN/USB/RS232/GPIB/CAN/External analog control interface	½ 2U
IT8514B+	500V	60A	1500W	0.1mV/1mA	±(0.025%+0.025%FS)/ ±(0.05%+0.05%FS)	Built-in LAN/USB/RS232/GPIB/CAN/External analog control interface	2U
IT8514C+	120V	240A	1500W	1mV/0.1mA	±(0.025%+0.025%FS)/ ±(0.05%+0.05%FS)	Built-in LAN/USB/RS232/GPIB/CAN/External analog control interface	2U

Dynamic test function

The dynamic test operation allows the electronic load to be switched between the two setting parameters according to the setting rules. This function is used to test the dynamic characteristics of the power supply.

♦ Continuous mode: Under continuous mode, When the dynamic test operation is enabled, load will be continuously switched between the A value and the B value .

♦ Pulse mode: Under pulse mode, when the dynamic test operation is enabled, each receive a trigger signal, the load will switch to the B value, after maintaining the B pulse width time, switch back to the A value.

♦ Toggle mode: In the trigger mode, when the dynamic test operation is enabled, each time a trigger signal is received, the load is switched between the A value and the B value.

Battery discharge test function

IT8500 + series electronic load can use constant current mode for battery discharge test. After the discharge test mode is selected, the test mode termination condition "switch off voltage value", "switch off capacity value" and "discharge time" can be set. When any of the three conditions is satisfied, the discharge is stopped and the electronic load is automatically switched is OFF state. Users can observe the battery voltage, time and battery discharge capacity during the test process.
