Brief introduction
The distortion measuring instrument is a new design of the company’s fully digital automatic distortion measuring instrument series. Its minimum distortion measurement reaches 0.01%, and the measurement frequency of the distortion signal reaches 110kHz. It is an intelligent instrument with a high performance/price
Performance characteristics
- With automatic distortion measurement function, automatic signal frequency measurement, and display
- Internal automatic calibration, automatic tracking filter
- The smallest measurable distortion is 0.01%
- It has the function of automatically measuring the signal-to-noise ratio (SINAD) and signal-to-noise ratio (S/N)
- With the function of measuring balanced or unbalanced signals
- Equipped with an oscilloscope output monitoring jack, convenient for users to observe the waveform of the signal under test
Technical index
Model | ZC4116 |
Display method | 160*32 LCD digital display |
input resistance | 100kΩ/100pF |
Additional filter | 400Hz、30kHz、80kHz |
Distortion measurement | |
Input signal range | 300mV-300V |
Distortion measurement range | 100%-0.01% |
Frequency range(unbalanced) | 10Hz-110kHz |
Frequency range(balanced) | 20Hz-40kHz |
Voltage measurement | |
Voltage measurement range | 300uV-300V |
Frequency range(unbalanced) | 10Hz-550kHz |
Frequency range(balanced) | 20Hz-40kHz |
Volume | 350mm×120mm×340mm |
